Tube and Pipe Bending - Prototype and Production

Meccom Corp. specializes in precision custom tube and pipe bending and rolling. We use mandrel bending for a more precise and perfect bend every time. We use over 100 bending dies. We bend square, rectangular, round shaped, pipes, tubing, square bar, and sheet metal in all types of materials and thick or thin walls.

Capabilities:
We bend tube up to 2-1/2"diameter
Pipe from 2-1/2"  up to 2-7/8" OD
We also specialize in rolling tube to 2" OD
Pipe to 1-1/2"
Sheet Metal from 1/4" thick up to 4 feet wide. All coils 		Materials:
Aluminum
Brass
Bronze
Copper
Some Exotic Metals - Thick and Thin Wall
spacer
Pipe Sizes

OD CL Radius
6.75 3/8 1-3/4 2.00 2-1/2 2-5/8
8.40 1/2 1-1/8 1-3/8 1-11/16 1-7/8 2-7/32 3-7/16 4-1/16
1.050 3/4 1-1/2 1-3/4 2.00 2-15/16 2-1/2 3.00 3-1/2 4-1/16 4-1/2 6-1/2 8.00
1.315 1.00 1-21/32 2.00 2-5/16 2-3/4 2-7/8 3.00 3-1/4 3-5/16 3-11/16 4.00 4-5/8 5-1/2 6.00
7-1/2 7-5/8 1-5/8 1-1/2
1.66 1-1/4 3.00 3-15/16 3-1/2 5-5/8 6-7/16 7-3/16
1.9 1-1/2 3.00 4.00 8.00 3-1/4 4-3/4 2-11/16 2-3/8 2.00 6-3/4 6-1/2
2.375 2.00 3.00 3-9/16 4.00 4-3/4 5.00 6.00 7.00 10.00
2.875 2-1/2 4.00 6.00 8-1/2 6-1/2
pipe bending
Tube Sizes

OD CL Radius
1/4 3/4
5/16 1/2 3/4 1.00
3/8 3/8 1/2 5/8 3/4 1.00 1-3/8 .656 .718
1/2 1/2 3/4 1.00 1-3/16 1-1/4 1-3/8 1-7/16 1-1/2 1-15/16 2.00 2-3/8 2-3/4
9/16 5/8 25/32 1-1/32 1-1/4 1-9/32 1-1/2 2-11/32
5/8 7/8 1.00 3/4 1-1/16 1-1/4 1-5/16 1-3/4 1-13/16 2.00 2-1/2 3-1/16 4.00
3/4 7/8 1-1/8 1-1/4 1-1/2 1-5/8 1-3/4 1-7/8 2.00 2-1/16 1-1/4 2-3/8 2-1/2 3-1/16 3-3/8 3-1/2
7/8 7/8 1-1/4 1-1/2 1-5/8 1-11/16 1-3/4 2.00 2-1/4 2-7/16 2-1/2 3.00 4.00 5.00 6.00 9.00
1.00 1.00 1-1/2 1-5/8 1-3/4 1-7/8 2.00 2-1/4 2-1/2 2-3/4 3.00 3-1/8 3-1/4 3-3/8 3-1/2
3-5/8 4.00 4-3/8 4-1/2 4-13/16 5-1/4 5-1/2 6.00 6-1/2 6-9/16 7-15/16
1-1/16 3.00
1-1/8 1-7/16 2-1/16 2-9/16 3-1/16 3-5/16 3-1/2 3-3/4 4.00 8.00
1-3/16 3-5/8
1-1/4 1-1/2 1-7/8 2.00 1-1/4 2-7/16 3.00 3-3/4 4.00 4-1/2 5.00 6.00 8.00 8-1/4
1-3/8 4.00 5.00 7.00
1-1/2 1-1/2 2.00 2-1/2 3.00 3-1/8 3-1/4 3-1/2 4.00 4-1/2 5.00 5-1/2 6.00 6-1/8 7-1/2
3-3/8 12-1/8
1-5/8 3-1/2 6.00 8.00 9.00 10.00
1-3/4 2-1/2 3.00 3-3/4 4-1/8 6.00
2.00 2-1/2 3.00 3-1/2 4.00 4-1/2 5.00 6.00 7.00 8.00 10.00 6-3/4 12.00 14.00
2-1/4 3.00 3-15/16 6.00
2-1/2 3-1/2 5.00 6.00 4-3/4 8-1/2 10.00
3.00 5.00
  30° = .523 R
45° = .785 R
60° = 1.046 R 		90° = 1.57 R
180° = 3.14 R
.01745 x R x Degrees
 tube rolling
Custom Tube Bending
